FEATURES
Fitness sorting | Tape, dog-ear, soil, tear, hole, graffiti, etc.
Multi currencies capability | Can recognize up to 15 currencies |
Various operating modes: Mixed/Single/Face/Orient/Count/Fitness/(Option: Issue/Serial No. Recognition & Comparison) |
New type of stacker | Lift type |
Enhanced sensors - Counterfeit Detector | CIS (Option: 2 CIS) /Magnetic/UV/IR/Mechanical Roller Tape Detection |
User friendly | Resistive touch screen + Hard Key, 5” TFT Color LCD
Multi Language Support
SPECIFICATION
2 + 1 Pocket
Size (W x D x H): 306[W] x 334[D] x 380[H] mm |
No. of Pockets: 3 + 1 (Reject) | Weight Approx. 20 Kg | Hopper capacity: MAX. 700 notes | Stacker1 capacity: 100 [Max.200] notes |
Stacker2 capacity: 100 [Max.200] notes | Reject pocket capacity: 50 [Max. 100] notes | Display Type: 800 x 480 Color LCD | Connectivity interfaces: 3 RS232C Port (9 Pin D-SUB & 2 Modular Jack),
2 USB (Type A & Type B), LAN | Currencies available: 1~15 (Available up to 15)
Banknote size range: W: 100 ~ 185, H: 60 ~ 90 mm |
Banknote thickness range: 0.08 ~ 0.12 mm
Counting Speed Approx.: 700/1000 notes/ mins | Working Mode: FITNESS / COUNT/ FACE/ ORIENT/
ISSUE/ DISPENSE/ POCR | Preset Batch Number: 1 – 200 |
Counterfeit Detection: MR-Array, MG, IR, UV |
Power Requirements: 100-240V~, 50~60Hz | Power Consumption: Standby: 16, Operation: 120 W
Operational requirements: 10~40deg/ 0~85%RH (Non Condensing)
